1280x1024 Ny fakan-tsary Network Network Network miaraka amin'ny lelan-doko 30 ~ 180mm

MODELY

SG - TCM12N2 - M30180

Sensor

Sary sensor

Vox Microbolometer Vox

vahaolana

1280 1024

Ny haben'ny piksel

12μm

Spectral Range

8 ~ 14μm

Hard

≤50mk @ 25 ℃, F # 1.0

family

Halavany

30 ~ 180ms môtô

Optical zoom

6x

Digital Zoom

4x

F Sarobidy

F1.0 ~ f1.4

Fov

28:302 ° × 23.15 ° ~ 4.89 ° × 3.91 °

Video

famatrarana

H.265 / H.264B / H.264m / H.264H / MJPEG

Snapshot

Jpeg

Loko Pseudo

Tohanana: Fotsy mafana, mafana mafana, vy mena, rainbow 1, fulgurite, rainbow 2, fusion, mena, amber, amber, Arctic, Tint

mikoriana

Renirano Mainty: 25 / 30fps @ 1280 × 1024, 25 / 30fps @ 704 × 576

Sub - renirano: 25 / 30fps @ 704 × 576, 25 / 30fps @ 352 × 240

Network

Protocol Network

IPv4, IPv6, HTTPS, HTCPS, UDP, RTP, RTP, RTP, RTP, FTP, DHCP, Ppoe, DNS, DDN, ICMN, ICMP, SNMP, ICOS, 802.1X, BONJOUR

Inseropability

ONVIF, API API, SDK, GB28181

Max. fifandraisana

20

fahiratan-tsaina

Hetsika ankapobeny

Motion, Tamper, karatra SD, Network

Ny fiasa IVS

Fitsangatsanganana, fiampitana fefy, fidirana, tsy fanelingelenana, haingam-pandeha, haingana - mifindra, fitetezana fijanonana, vahoaka manangona vinavina, tsy hita, zavatra tsy hita, zavatra tsy hita, zavatra tsy hita.

Fikarohana afo

MANAMPY

interface tsara

Eternet

Open book 01.svg Bika matoanteny

HD - SDI (Safidy)

1Ch HD - SDI

Fanairana ao / mivoaka

1/1

Audio in / out

1/1

Rs485

MANAMPY

vahaolana

50hz: 25Fps @ (1280 × 1024)

Fahaiza-manao fitahirizana

Micro SD / SDHC / SDXC Card (hatramin'ny 1TB) Fivarotana sisiny, FTP, NAS

Herin'aratra

DC 12V, 1a

Toe-javatra miasa

- 30 ° C ~ + 60 ° C / 20% hatramin'ny 80% rh

Toerana fitahirizana

- 40 ° C ~ + 70 ° C / 20% ka hatramin'ny 95% rh

Dimysions (l * w * h)

Eo ho eo. 295mm * 155mm * 155mm

Lanja

Eo ho eo. 3.2kg
