| MODELY | SG-PTD2030NL | ||||
| Sensor | Image Sensor | 1/2.8” Sony Starvis progressive scan CMOS | |||
| Pixels mahomby | Approx.2.13 Megapixel | ||||
| family | Focal Length | 4.7mm~141mm, 30x Optical Zoom | |||
| nisara- | F1.5~F4.0 | ||||
| Field of View | H: 61.2°~2.2°, 36.8°~1.2°, D: 68.4°~2.5° | ||||
| Akatona Focus Distance | 1m~2m (Wide~Telefaonina) | ||||
| Haingana Zoom | Approx.3.5s (Optical Wide~Telefaonina) | ||||
| Distance DORI(Olombelona) | mahita | Tandremo | NY FOMBA ANEHOAN'ANDRIAMANITRA | FANTARO | |
| 1,999m | 793m | 399m | 199m | ||
| Video | famatrarana | H.265/H.264/H.264H/MJPEG | |||
| Stream Capability | 3 riaka | ||||
| vahaolana | 50Hz: 25fps@2MP(1920×1080), 25fps@1MP(1280×720)60Hz: 30fps@2MP(1920×1080), 30fps@1MP(1280×720) | ||||
| Vidéo Bit Rate | 32kbps~16Mbps | ||||
| teny | AAC / MP2L2 | ||||
| Tambajotra | fitahirizana | Karatra TF (256 GB), FTP, NAS | |||
| Network Protocol | Onvif, HTTP, HTTPS, IPv4, IPv6, RTSP, DDNS, RTP, TCP, UDP | ||||
| Multicast | MANAMPY | ||||
| Hetsika ankapobeny | Motion, Tamper, SD Card, Network | ||||
| IVS | Tripwire, Fikarohana Cross Fefy, Fidirana, Zavatra nilaozana, Mivezivezy haingana, Fikarohana Parking, Tombantomban'ny Fiangonan'ny Vahoaka, Zavatra tsy hita, Fikarohana Mivezivezy. | ||||
| Ny tahan'ny S/N | ≥55dB (AGC miala, lanja ON) | ||||
| Fahazavana kely indrindra | Loko: 0.005Lux/F1.5;B/W: 0.0005Lux/F1.5 | ||||
| Fampihenana ny tabataba | 2D/3D | ||||
| Fomba fisehosehoana | Auto, Aperture priority, Shutter priority, Gain priority, Manual | ||||
| Tambin-karama | MANAMPY | ||||
| Shutter Speed | 1/1~1/30000s | ||||
| BLC | MANAMPY | ||||
| KMH | MANAMPY | ||||
| WDR | MANAMPY | ||||
| IR | 250m | ||||
| White Balance | Auto, Manual, Indoor, Outdoor, ATW, Jiro Sodium, Jiro an-dalambe, Voajanahary, Tosika iray | ||||
| Andro/alina | Elektrika, ICR(Auto/Manual) | ||||
| Focus Mode | Auto, Manual, Semi Auto, Fast Auto, Fast Semi Auto, One Push AF | ||||
| Electronic Defog | MANAMPY | ||||
| Atsimbadiho | MANAMPY | ||||
| EIS | MANAMPY | ||||
| Zoom nomerika | 16x | ||||
| PTZ | Salan'ny Pan/Tilt | Pan: 360°;Mitongilana: -10°-90° | |||
| Pan Speed | Configurable, pan: 0.1°-150°/s;hafainganam-pandeha efa napetraka: 180°/s | ||||
| Haingana mitongilana | Azo amboarina, mitongilana: 0.1°-90°/s;hafainganam-pandeha efa napetraka: 90°/s | ||||
| OSD | MANAMPY | ||||
| Faritra Zoom In | MANAMPY | ||||
| PTZ haingana | MANAMPY | ||||
| Faritra mifantoka | MANAMPY | ||||
| Presets | 255 | ||||
| fisafoana | 4 Patrol, hatramin'ny preset 10 isaky ny fisafoana | ||||
| NOMEKO | 1 lamina scan, hetsika 32 azo raketina tsy tapaka | ||||
| Line Scan | 1 | ||||
| 360° Pan Scan | 1 | ||||
| Idle Motion | Ampidiro ny Preset/Scan/Tour/Pattern/Pan Scan | ||||
| Ampaherezo ny hetsika | Ampidiro ny Preset/Scan/Tour/Pattern/Pan Scan | ||||
| Park Action | Preset/Patrol/Patterna | ||||
| Fanaraha-maso fiara | MANAMPY | ||||
| interface tsara | Herin'aratra | DC12V | |||
| GND | GND (PTZ trano sy famatsiana herinaratra) | ||||
| Ethernet | RJ45(10Base-T/100Base-TX) | ||||
| Audio I/O | 1/1 | ||||
| Fanairana I/O | 1/1 | ||||
| RS485 | 1 | ||||
| RS232 | 1 | ||||
| Fepetra miasa | (-20°C~+60°C/20% hatramin'ny 95%RH) | ||||
| Herin'aratra | DC 12V/4A, PoE | ||||
| Fanjifana herinaratra | Andro: 6W;Patrol: 9W;Alina (Patrol+ IR): 28W | ||||
| Ambaratonga fiarovana | IP66;TVS 6000V tselatra fiarovana, fisorohana firongatry, B/T17626.5 | ||||
| refy (L*W*H) | Φ237mm × 335mm | ||||
| lanja | 6 kg | ||||
